# pxlba generated file

　　# pxlBA.txt ： Extract file used to extract properties for

　　# back annotation using packagerxl. Refer to Allegro extract

　　# documentation for more details on the syntax of this file

　　# and the Extract program.

　　# The lines starting with # are comments.

　　# The default version of this file extracts the minimum number

　　# of properties necessary to ba changes to packaging.

　　# To extract additional properties the user must remove the

　　# comment character ‘#’ from the appropriate lines. Or

　　# add a line with the property name to the appropriate section.

　　# a2pxl looks for this file in the current working directory.

　　# If it is not found there， it looks for it

　　# in the hierarchy in the following location：

　　# 《installation dir》/tools/pcb/text/views

　　# Connection view. File： pinView.dat

　　#

　　LOGICAL_PIN

　　# These properties must not be removed， moved or modified.

　　# vvvvvvvvvvvvvvvvvvv

　　NET_NAME

　　REFDES

　　PIN_NUMBER

　　FUNC_LOGICAL_PATH

　　COMP_DEVICE_TYPE

　　FUNC_SCH_SIZE

　　FUNC_HAS_FIXED_SIZE

　　FUNC_DES

　　# ^^^^^^^^^^^^^^^^^^^

　　# Any other PIN properties to be back annotated show up here.

　　PIN_NET_SHORT

　　PIN_NO_SWAP_PIN

　　PIN_NO_PIN_ESCAPE

　　PIN_PIN_ESCAPE

　　PIN_PIN_SIGNAL_MODEL

　　PIN_NO_DRC

　　PIN_NO_SHAPE_CONNECT

　　END
