INTEL NUC nuc6i3syb

Rev. Page Note

A2 23 Modify DDI Port 2 to be Display Port. A2 24 Modify DDI Port 1 to be HDMI Port and change HDMI CONN to be Full size. A2 33 Add pull high resistor for V1P0S_PG. A2 34 Change C239 to be 0402 size. A2 26 Add SQ19 to be a reverser. A2 26 Modify the pull high voltage source for SD detect signal. C Add GPIO PIN AD3，AD4 Modify pull high resistance R201→49.9K，R441→49.9K 4 C 8 Modify resistance R192→0 ohm Modify crystal capacity SC258 & SC269→12p C Fix DSW mode sequence issue， add RJ18 & R30 & Q26， 9 modify SR138→ un-stuff Fix CPU sequence issue，C120→stuff C 10 For EMI request add SRN6 C Fix hardwave strip voltage high R189 15 →1K Remove reverse GPIO pin AN7 & AP5 20 Fix VCC3 leakage R149→un-stuff Space issue R135 & R191 & C104 & R136 & R141→R0201 Fix CPU sequence issue C113 & C115 & C119→stuff C C 19 Add AUDIO connector 2nd & 3rd source C Add Q22 2nd & 3rd source 23 23 Fix G3 to S5 Power LED always light issue ，add Q27 & R363 & R440 Fix SATA LED issue， add pull high R259 C C Fix IMVP tool test issue， modify C43 & C47 & R44 & 27 R73 & C49 & R78 & C70 C 26 Fix SD card function issue， add SR2→22ohm & SR161→stuff C 31 Fix CPU sequence issue，remove Q18 & R363， C61 & C143→stuff C Fix USB power in S3/S4/S5 issue，modify Q21， add R4 17 42 & change GPIO AR7→AP5 C 28 Fix IMVP tool test issue， modify SC64 & SC50 & SR37 & SR68 & SR78 & SR92 & SR73 & SC70 & SR86 & SC107 C 29 Fix IMVP tool test issue， modify R126 & R130& C93 & R131& C95 & R131 & C82 & R130 & R161 & C108 C 30 Fix CPU sequence issue， modify R352→200ohm， add R439， C184→stuff Modify pull high resistance R371→4.7K， Remove PMIC sequence PIN K5 C 33 C Fix CPU sequence issue， add D8， R277 & C152 34 →stuff C 32 Change GPIO AD3→AM5 ， AD4→AN7 C 20 Change GPIO AD4→AN7 C 31 ADD R443 100K Ohm C For Damon‘s cost down solution， it is shown on the picture
