可以加熱的MOSFET

　　功率MOSFET以其低電容和良好的高頻開關特性，在電力電子設計中得到了廣泛的應用。他們已經進入了許多應用領域，并幫助開辟新的應用市場，從混合動力和電動汽車到太陽能到極端環境探測。這些環境的統一因素是熱。汽車發動機和太陽能電池板能夠產生熱量，使功率器件的結溫遠高于100°C。這種熱量會嚴重影響功率半導體，而這些半導體并不是用來應付的。

　　功率半導體都有溫度限制。泄漏電流隨著溫度的升高而增加，這會加速導致?lián)舸l件的影響，從而損壞電路并造成其他危險。

　　所有半導體額定電壓為一個給定的最大反向電壓。如果設備在高于這種電壓的情況下工作，反向偏置電場就會產生高電場。這些電場足夠強，可以把帶電粒子加速到高能量。當這些加速的載流子擊中電子與原子結合時，它們轉移足夠的能量以破壞原子鍵并形成電子空穴對。在高電場下，它們會朝相反的方向加速，并有可能撞擊其他固定電子，使它們自由旋轉。結果是雪崩擊穿，破壞了功率半導體中的二極管層，使器件失去了功能。

　　Even if the device is not irreparably damaged， as some devices are designed to withstand a certain amount of avalanche current， a hysteresis effect means the voltage has to drop significantly before the reverse current is shut off， potentially causing damage to other components in the system.

　　In silicon， heat tends to accelerate the process of avalanche breakdown because higher temperatures will impart thermal energy to valence electrons in the crystal lattice of the power device. As more thermal energy is absorbed， some of those valence electrons will break free of their bonds and move into the conduction bands. Inductive loads increase the risk of breakdown because of the high reverse-bias conditions they can impose on the diode junctions inside a power transistor when used with switching power-supply circuitry.
