The AP7215 low-dropout linear regulator operates from a 3.3V to 5.5V supply and delivers a guaranteed 600mA continuous load current. The high-accuracy output voltage is preset to an internally trimmed voltage. An active-low open-drain reset output remains asserted for at least 20ms （TYP） after input voltage rises above the reset threshold. The space-saving SOP-8L and SOT89-3L package are suitable for “pocket” and hand-held applications.

　　Very Low Dropout Voltage ? Low Current Consumption： Typ. 50μA ? Output Voltage： 3.3V ? Guaranteed 600mA Output ? Input Range up to 5.5V ? Current Limit Protection ? Stable with either electrolytic capacitor or low-ESR MLCC （multi-layer ceramic capacitor） Low Temperature Coefficient ? SOP-8L and SOT89-3L： Available in “Green” Molding Compound （No Br， Sb） ? Lead Free Finish / RoHS Compliant （Note 1）
