The ISL88016， ISL88017 supervisors offer pin-selectable voltage trip points along with popular functions such as Power-on Reset control， Supply Voltage Supervision， and Manual Reset assertion in a small 6 Ld TSOT-23 package. By connecting the three VSET pins to VDD， GND or floating， users can program the voltage trip point from 1.60V to 2.85V in 50mV increments on the ISL88016 and from 2.15V to 4.65V in 100mV increments on the ISL88017. These userselectable reset threshold voltages are accurate to ±2% over temperature and the reset signal is valid down to 1V. Intersil’s proprietary TwinPin? combines the active low reset out with the manual reset input into one pin. This provides device adjustability without sacrificing functionality. These parts are specifically designed for low power consumption and high threshold accuracy
