The AD9204 operates from a single 1.8 V analog power supply and features a separate digital output driver supply to accommodate 1.8 V to 3.3 V logic families. 2. The patented sample-and-hold circuit maintains excellent performance for input frequencies up to 200 MHz and is designed for low cost， low power， and ease of use. 3. A standard serial port interface supports various product features and functions， such as data output formatting， internal clock divider， power-down， DCO/DATA timing and offset adjustments， and voltage reference modes. 4. The AD9204 is packaged in a 64-lead RoHS compliant LFCSP that is pin compatible with the AD9268 16-bit ADC， the AD9251 and AD9258 14-bit ADCs， and the AD9231 12-bit ADC， enabling a simple migration path between 10-bit and 16-bit converters sampling from 20 MSPS to 125 MSPS.
