The AD7392/AD7393 comprise a set of pin-compatible 10-/12-bit voltage output， digital-to-analog converters. The parts are designed to operate from a single 3 V supply. Built using a CBCMOS process， these monolithic DACs offer low cost and ease of use in single-supply 3 V systems. Operation is guaranteed over the supply voltage range of 2.7 V to 5.5 V， making this device ideal for battery-operated applications. The full-scale voltage output is determined by the external reference input voltage applied. The rail-to-rail REFIN to DACOUT allows a full-scale voltage equal to the positive supply VDD or any value in between. The voltage outputs are capable of sourcing 5 mA. A data latch load of 12 bits with a 45 ns write time eliminates wait states when interfacing to the fastest processors. Additionally， an asynchronous RS input sets the output to a zero scale at power-on or upon user demand. Both parts are offered with similar pinouts， which allows users to select the amount of resolution appropriate for their applications without changing the circuit card. The AD7392/AD7393 are specified for operation over the extended industrial temperature range of ?40°C to +85°C. The AD7393AR is specified for the automotive temperature range of ?40°C to +125°C. The AD7392/AD7393 are available in 20-lead PDIP and 20-lead SOIC packages. For serial data input， 8-lead packaged versions， see the AD7390 and AD7391.
