The 200 mA dual output ADP220/ADP221 combine high PSRR， low noise， low quiescent current， and low dropout voltage in a voltage regulator ideally suited for wireless applications with demanding performance and board space requirements. The low quiescent current， low dropout voltage， and wide input voltage range of the ADP220/ADP221 extend the battery life of portable devices. The ADP220/ADP221 maintain power supply rejection greater than 60 dB for frequencies as high as 100 kHz while operating with a low headroom voltage. The ADP220 offers much lower noise performance than competing LDOs without the need for a noise bypass capacitor. The ADP221 also includes an active pull-down to quickly discharge output loads. The ADP220/ADP221 are available in a miniature 6-ball WLCSP package and 6-ball bumped bare die and is stable with tiny 1 μF ± 30% ceramic output capacitors， resulting in the smallest possible board area for a wide variety of portable power needs. The ADP220/ADP221 are available in many output voltage combinations， ranging from 0.8 V to 3.3 V， and offer overcurrent and thermal protection to prevent damage in adverse conditions.
